Made of grade 304 solid 1/8' thick Stainless Steel. Shallow profile, 1' depth on pan. Drain pan has a small flange lip to provide a surface to silicone for a water-tight seal, as well as mounting in place with concrete screws/anchors if needed. Custom made size Stainless Steel Drain Pans are sold here. Stainless Steel Slot Drains Favoured by landscape architects, our slot drain has been designed to offer a very discreet but highly effective channel drainage solution. The slot channels maximise flow capacity while minimising the profile visible at ground level, allowing it to fit within the surrounding area. Slot Drain does not absorb water or contaminates and allows any solids to be disposed of in an environmentally friendly manner. The only part of Slot Drain that is exposed is the stainless steel surface which can be cleaned and sanitized in the same manner as your floor surface. Watch how easy it is to clean a Slot Drain System. Mar 01, 2020 - 18 Gauge, 304L stainless steel slot, 16 Gauge 304L SS tile insert clean out with stainless steel channel - Finished width: 3/8', Min. Height above waterproofing: 1-1/16' - Capacity: 9 gallons per minute. Stainless Steel Slot Drains With over 40 years of experience building commercial and industrial stainless steel slot drains, we want to be your trusted partner for your next project. We can work with your design or let us help you design a slot drain system that meets your needs. Put our industry experience and expertise to work for you!

StainlessDrains.com is well known for high quality, precisely dimensioned custom drains. We have completed large fountain drain projects that incorporated area drains, trench drains and parapet drains. StainlessDrains.com has also custom designed radius slot drains for large outdoor fountain parks.

Our keystone project involved working with architects, engineers and contractors to construct a radius slot drain to encircle a fountain park. The fountain park was designed as a play area for children, so precise tolerances were required to avoid creating foot traffic hazards for users of the fountain park. StainlessDrains.com designed over 1,000 feet of slot drain to conform to the various twists and turns of the fountain area.

Slot

The project planners sent us the fountain park plans, and we fabricated the slot drains to follow the exact drain pattern required to not only drain the fountain area, but to enhance the aesthetics of the fountain. We shipped each drain components labeled with its corresponding component and area location to ensure the field crew could properly align and install each component. All components were installed without any rework required.

Drain Pan Water Heater

Our experience with fountain drains demonstrates the ability of StainlessDrains.com to customize our products for any requirement.

We have the ability to create up to 360° custom and radius slot drains that are connected using only field welds. This leaves a seamless top and a solid body. No flanges or bolts required. The additional benefits of a field weld include decreased installation costs, superior appearance and a lifetime performance.

StainlessDrains.com welcomes the challenges of unique projects. Our flexibility allows us to meet the needs of your fountain drain project. Your project will not be confined by out-of-the-box standard components when you call StainlessDrains.com.

Radius Slot Drains Configuration

Standard Configuration Slot Drains Include:

  • 304 or 316 Stainless Steel Construction
  • Shipping Length up to 50’ Sections
  • 1” Standard Slot Opening
  • Placement and Number of Outlet to Customer Specification
  • Schedule 10, 40 or 80 Outlets
  • Standard Outlet Sizes of 2”, 3”, 4” or 6”
  • 1/8” Per Foot Slope
Slot Drain Pan Stainless Steel

Fountain Drain Options

  • Custom Slopes
  • Custom Outlet Sizes
  • Custom Slot Width Opening
  • Circular (Radial) Construction Available up to 360°

To inquire about a quote from StainlessDrains.com fill out our contact form or call us at 888.387.4045.
CDI 22
Cast iron clamp down floor drain
2' throat, 2' no hub outlet
4-1/2' L x 3-3/4' W x 3-1/16' H
Waterproofing: PVC/Vinyl liner, Lead/copper pan, Hot mop, Rubber liner, Fiberglass
CDA 22
ABS clamp down floor drain
2' throat, 2' outlet
4-1/2' L x 3-3/4' W x 3-1/16' H
Waterproofing: PVC/Vinyl liner, Rubber liner, Fiberglass

Slot Drain Pan Stainless Steel Indian

CDP 22
PVC clamp down floor drain
2' throat, 2' outlet
4-1/2' L x 3-3/4' W x 3-1/16' H
Waterproofing: PVC/Vinyl liner, Rubber liner, Fiberglass
UCP 2
Universal 2' throat clamping plate – cast iron
6-1/2' overall diameter
Allows adaptation to hot mop type drain bodies: Oatey 151, EZ Text, Frank Pattern Instant Set
Works with threaded connections TNAS and S 50

Slot Drain Pan Stainless Steel Or Cast Iron

TNAS
2' stainless steel threaded nipple
Straight thread
For use with S-AS 65, S-DGAS 65, S-TIFAS 65 and all FX Series except FX 125

Slot Drain Pan Stainless Steel Cookware

HS 2
2' hair strainer for all standard flow drains except FF 25 and FT 25 Series

Low Profile Drain Pan

AKEY
Lift-out Key for: S-AG 38, S-AG 65, S-AG 100, S-AS 65, S-AS 99, S-TIF 65, S-TIFAS 65, S-TIFAS 99 FXAS 65, FXAS 125, FXED 65, FXTIF 65 FFAS 25, FFAS 65, FFAS 125, FFED 25, FFED 65, FFTIF 65 FTAS 25, FTAS 65, FTED 25, FTED 65, FTTIF 65, WW5-2
